Apply to RO Reverse Osmosis system home using water dispenser,commercial application water purifier,pipeline machine, drinking water machine, coffee machine etc
1,Product Structure：Pilot type Normal Closed
2,Port size：G1/4 or NPT1/4 female Jaco connector,Or Quick push-in 1/4 Inch Hose
3,Voltage ：DC12V、DC24V、DC36V、DC230V、AC110V、AC220V
4,Working Water pressure：0~0.8Mpa
5,Working Medium：1~100℃ Public using water
6,Water pressure endurance:Tested 2.0Mpa for 10Minutes no abnormity
7,Coil free mounting
8,Life cycle：100000 cycles
9,For control the wastewater,must to match with the Flow Restrictor
FCD-280 Water inlet solenoid valve with Flow Restrictor combination
1,Product Structure：Pilot type Normal Closed
2,Port size：G1/4 or NPT1/4 female Jaco connector,Or Quick push-in 1/4 Inch Hose
3,Voltage ：DC12V、DC24V、DC36V、DC230V、AC110V、AC220V
4,Working Water pressure：0~0.8Mpa
5,Working Medium：1~100℃ Public using water
6,With flow Restrictor and Wastewater flow at 0.5Mpa is 300cc/min
7,Water pressure endurance:Tested 2.0Mpa for 10Minutes no abnormity
8,Coil free mounting
9,Life cycle：100000 cycles
FCD-016 18 seconds Water inlet automatic washing combination solenoid valve
1,Product Structure：Pilot type Normal Closed
2,Port size：G1/4 or NPT1/4 female Jaco connector,Or Quick push-in 1/4 Inch Hose
3,Voltage ：DC12V、DC24V、DC36V
4,Working Water pressure：0~0.8Mpa
5,Working Medium：1~100℃ Public using water
6,With flow Restrictor and Wastewater flow at 0.5Mpa is 300cc/min
7,Water pressure endurance:Tested 2.0Mpa for 10Minutes no abnormity
8,Power on automatic washing time:18S
9,Life cycle：100000 cycles
